Performance |
Index |
Supplement |
TX&RX Optical feature |
Operating wavelength |
(nm) |
1528~1563 |
100GHz, ITU standard wavelength |
| Wavelength adjustable range |
(nm) |
±1.6 |
±200GHz |
| Wavelength adjustable mode |
|
±0.05nm stepping |
|
| Wavelength stability |
(pm/℃) |
-1~0 |
TC＝20~70℃ |
| Size mode suppression tatio |
(dB) |
>45 |
SMSR |
| Equivalent noise level |
(dB/Hz) |
≤-160 |
20~1000MHz(CATV) |
≤-145 |
20~2700MHz(SAT-IF) |
| Number of TX output port |
|
1 |
HDBS-5100DW1 |
5 |
HDBS-5100DW5 |
| TX output power1) |
(dBm) |
6.0 (4mW) |
HDBS-5106DW口-TX |
10.0 (10mW) |
HDBS-5110DW口-TX |
| Number of RX input port |
|
1 |
HDBS-5000DW1-RX |
5 |
HDBS-5000DW5-RX |
| RX responsibility |
(A/W) |
≥0.9 |
1550nm |
| RX input power range |
(dBm) |
0 ~ -13 |
|
| Number of RX output port |
|
1 |
RW (for ONU) |
| Return loss |
(dB) |
≥50 |
|
| Connector |
|
SC/APC |
Option FC/APC, LC/APC |
| Laser type |
|
Cooling DFB |
TX with ISO |
| Optical receive tube type |
|
PIN |
RX |
SAT-IF feature |
Operating bandwidth |
(MHz) |
950~2400 |
|
| TX input level |
(dBmV) |
-25 ~ -14 |
TG with IF amplification (AGC) |
-6 ~ +10 |
TO without IF amplification |
| RX output level |
(dBmV) |
-15 ~ -40 |
RX |
| Flatness |
(dB) |
0.5 |
40MHz |
±1.0 |
950~2400MHz |
| Input impedance |
(Ω) |
75 |
|
| RF return loss |
(dB) |
12 |
|
| RF connector |
|
F-female |
|
| C/IM3 2) |
(dB) |
≥55 |
|
| Equivalent noise level |
(dB/Hz) |
>115 |
|
| Link gain3) |
(dB) |
25 |
|
CATV adopt DMTX feature |
Operating bandwidth |
(MHz) |
45~862 |
|
| Input level |
(dBmV) |
15~25 |
AGC |
| Flatness |
(dB) |
≤±1.0 |
45~862MHz |
| Return loss |
(dB) |
>16 |
|
| RF connector |
|
F-female |
|
| Impedance |
(Ω) |
75 |
|
| CNR |
|
≥50.5 |
PAL-D/60CH |
| CTB |
|
≤-63 |
|
| CSO |
|
≤-58 |
≤600MHz |
≤-53 |
>600MHz |
| Transmission distance |
(Km) |
5 |
D05 |
10 |
D10 |
15 |
D15 |
General feature |
Serial interface |
|
RS232 |
|
| SNMP network management interface |
|
RJ45 |
|
| Power supply |
(V) |
95~260VAC |
|
| Power consume |
(W) |
<50 |
|
| Operating temp. |
(℃) |
-5 ~ +65 |
|
| Relative humidity |
(%) |
<85 |
|
| Size (W)×(D)×(H) |
HDBS-5100 |
|
19×10.5×1.75 ( " )
483×267×44 ( mm )
|
|
HDBS-5200 |
|
10.4×7.8×1.38 ( " )
263×198×35 ( mm ) |
|
Remarks: 1. DWDM insertion loss is not included.
2. C/IM3 is defined as the ratio between the peak of carrier signal and triple beat (IM3) by using a two-tone test (1.0GHz and 1.1GHz).
3. -40dBm RF input test
 Link performation
Fiber input (dB) |
Link loss(dB) |
CNR (dB) |
Link gain (dB) |
RF output level (dBm/Ch.) |
-13 |
14 |
30.18 |
-2 |
-38 |
-12 |
13 |
32.18 |
0 |
-36 |
-11 |
12 |
34.13 |
2 |
-34 |
-10 |
11 |
38.59 |
6 |
-32 |
-8 |
9 |
40.11 |
8 |
-30 |
-7 |
8 |
42.18 |
10 |
-28 |
-6 |
7 |
44.24 |
12 |
-26 |
-5 |
6 |
45.67 |
14 |
-24 |
-4 |
5 |
46.53 |
16 |
-22 |
-3 |
4 |
46.76 |
18 |
-20 |
-2 |
3 |
46.92 |
20 |
-18 |
-1 |
2 |
47.01 |
22 |
-16 |
0 |
1 |
47.03 |
24 |
-14 |
Remarks: 1. DWDM insertion loss is not include, TX Output=6dBm.
2. Digital satellite receiver input level typical is -60dBm ~ -30dBm.
100GHz DWDM technical index
Performance |
DWDM-1008 |
DWDM-1016 |
DWDM-1032 |
| Operating wavelength |
(nm) |
C/L-Band |
| Operating center wavelength |
|
ITU |
| Center wavelength accuracy |
(nm) |
±0.3 |
| Channel spacing |
(nm) |
100 |
| Channel passband (@-0.5dB bandwidth) |
(nm) |
≥0.22 |
| Passband insertion loss (without connector) |
(dB) |
≤3.0 |
≤5.2 |
≤10.0 |
| Channel consistency |
(dB) |
≤1.5 |
≤2.0 |
≤3.0 |
| Channel ripple |
(dB) |
≤0.5 |
| Isolation |
Adjacent |
(dB) |
≥30 |
Non-adjacent |
≥40 |
| Polarization dependence loss |
(dB) |
≤0.15 |
| Polarization mode dispersion |
(ps) |
≤0.10 |
| Directivity |
(dB) |
≥50 |
| Return loss |
(dB) |
≥50 |
| Power handling |
(mW) |
≤500 |
| Interface type |
|
NO |
| Fiber type |
|
SMF-28e with 900um loose tube |
| Fbier length |
(m) |
≥1.0 (Modulator) |
| Operating temp. |
(℃) |
0 ~ +70 |
| Storage temp. |
(℃) |
-40 ~ +85 |
| Optical connector |
|
SC/APC, option LC/APC, FC/APC |
| Size |
Modulator |
(mm) |
120×80×12 |
120×80×18 |
120×115×14.5 |
19“ stander |
(") |
19×10×1.75 |
Wavelength configuration table  ITU-TG.692 C-Band 100GHz (0.8nm) Wavelength configuration table
Chanel number |
Frequency (THz) |
Operating wavelength (nm) |
Chanel number |
Frequency (THz) |
Operating wavelength (nm) |
61 |
196.1 |
1528.77 |
38 |
193.8 |
1547.72 |
60 |
196.0 |
1529.55 |
37 |
193.7 |
1545.32 |
59 |
195.9 |
1530.33 |
36 |
193.6 |
1548.51 |
58 |
195.8 |
1531.12 |
35 |
193.5 |
1549.32 |
57 |
195.7 |
1531.90 |
34 |
193.4 |
1550.12 |
56 |
195.6 |
1532.68 |
33 |
193.3 |
1550.92 |
55 |
195.5 |
1533.47 |
32 |
193.2 |
1551.72 |
54 |
195.4 |
1534.25 |
31 |
193.1 |
1552.52 |
53 |
195.3 |
1535.04 |
30 |
193.0 |
1553.33 |
52 |
195.2 |
1535.82 |
29 |
192.9 |
1554.13 |
51 |
195.1 |
1536.61 |
28 |
192.8 |
1554.94 |
50 |
195.0 |
1537.40 |
27 |
192.7 |
1555.75 |
49 |
194.9 |
1538.19 |
26 |
192.6 |
1556.55 |
48 |
194.8 |
1538.98 |
25 |
192.5 |
1557.36 |
47 |
194.7 |
1539.77 |
24 |
192.4 |
1558.17 |
46 |
194.6 |
1540.56 |
23 |
192.3 |
1558.98 |
45 |
194.5 |
1541.35 |
22 |
192.2 |
1559.79 |
44 |
194.4 |
1542.14 |
21 |
192.1 |
1560.61 |
43 |
194.3 |
1542.94 |
20 |
192.0 |
1561.42 |
42 |
194.2 |
1543.73 |
19 |
191.9 |
1562.23 |
41 |
194.1 |
1544.53 |
18 |
191.8 |
1563.05 |
40 |
194.0 |
1545.12 |
17 |
191.7 |
1563.86 |
39 |
193.9 |
1546.92 |
|
|
|
HDBS-5000DW standard wavelength configuration (S)
VL-SAT-IF |
1550.92nm |
HL-SAT-IF |
1555.75nm |
VH-SAT-IF |
1552.52nm |
HH-SAT-IF |
1557.36nm |
Product series TX & RX
Model |
Optical power (dBm) |
Number of RX |
Number of output ports |
Wavelength configuration |
Connector |
SAT-IF |
CATV |
SAT-IF |
CATV |
Input |
Output |
Pass |
HDBS-5106DW1-TG-D05-S |
6 |
6 |
- |
- |
- |
1 |
- |
S |
SC/APC |
HDBS-5106DW1-TG-D10-S |
- |
- |
- |
HDBS-5106DW1-TG-D15-S |
- |
- |
- |
HDBS-5110DW1-TG-D05-S |
10 |
10 |
- |
- |
- |
1 |
- |
S |
HDBS-5110DW1-TG-D10-S |
- |
- |
- |
HDBS-5110DW1-TG-D15-S |
- |
- |
- |
HDBS-5106DW5-TG-D05-X |
6 |
6 |
- |
- |
- |
5 |
- |
X |
HDBS-5106DW5-TG-D10-X |
- |
- |
- |
HDBS-5106DW5-TG-D15-X |
- |
- |
- |
HDBS-5110DW5-TG-D05-X |
10 |
10 |
- |
- |
- |
5 |
- |
X |
HDBS-5110DW5-TG-D10-X |
- |
- |
- |
HDBS-5110DW5-TG-D15-X |
- |
- |
- |
HDBS-5106DW1-TG-E16-S |
6 |
6 |
- |
- |
- |
1 |
- |
S |
HDBS-5106DW5-TG-E16-X |
- |
- |
- |
5 |
- |
X |
HDBS-5110DW1-TG-E10-S |
10 |
10 |
- |
- |
- |
1 |
- |
S |
HDBS-5110DW5-TG-E10-X |
- |
- |
- |
5 |
- |
X |
HDBS-5106DW1-TG-O41-S |
6 |
0 |
- |
- |
- |
1 |
- |
S |
HDBS-5110DW1-TG-O41-S |
10 |
- |
- |
- |
HDBS-5106DW1-TG-Q51-S |
6 |
6 |
- |
- |
- |
1 |
- |
S |
HDBS-5110DW1-TG-Q51-S |
10 |
10 |
- |
- |
- |
HDBS-5113DW1-RX-R41-S |
- |
- |
4 |
1 |
1 |
- |
- |
S |
HDBS-5113DW1-RX-R42-S |
- |
- |
2 |
HDBS-5113DW5-RX-R41-X |
- |
- |
4 |
1 |
5 |
- |
- |
X |
HDBS-5113DW6-RX-R42-X |
- |
- |
2 |
6 |
HDBS-5113DW1-RW-R41-S |
- |
- |
4 |
1 |
1 |
- |
1 |
S |
HDBS-5113DW1-RW-R42-S |
- |
- |
2 |
HDBS-5113DW5-RW-R41-X |
- |
- |
4 |
1 |
5 |
- |
1 |
X |
HDBS-5113DW6-RW-R42-X |
- |
- |
2 |
6 |
Remarks: 1. CWDM insertion loss is not include.
2. TX can choose TO type, without IF amplify.
DWDM
Model |
Exterior |
Number of optical port |
Pass wavelength (nm) |
Connector |
Input |
Output |
Pass |
DWDM-1004-TX-C-SA |
19" stander |
1 |
4 |
- |
Optional |
SC/APC |
DWDM-1008-TX-C-SA |
1 |
8 |
- |
Optional |
SC/APC |
DWDM-1016-TX-C-SA |
1 |
16 |
- |
Optional |
SC/APC |
DWDM-1032-TX-C-SA |
1 |
32 |
- |
Optional |
SC/APC |
DWDM-1004-RX-C-SA |
19" stander |
4 |
1 |
- |
Optional |
SC/APC |
DWDM-1008-RX-C-SA |
8 |
1 |
- |
Optional |
SC/APC |
DWDM-1016-RX-C-SA |
16 |
1 |
- |
Optional |
SC/APC |
DWDM-1032-RX-C-SA |
32 |
1 |
- |
Optional |
SC/APC |
DWDM-1004-RW-C-SA |
19" stander |
4 |
1 |
1 |
1310/1490 |
SC/APC |
DWDM-1008-RW-C-SA |
8 |
1 |
1 |
1310/1490 |
SC/APC |
DWDM-1016-RW-C-SA |
16 |
1 |
1 |
1310/1490 |
SC/APC |
DWDM-1032-RW-C-SA |
32 |
1 |
1 |
1310/1490 |
SC/APC |
Remarks: 1. Module type adjustable (M).
2. Channel number and channel wavelength can by specify by users.
|
TX & RX
